This page was created as a guide for collectors to use when discussing different features of a rifle that they would like to see pictures of. The firearm is a Soviet M38, but the pictures may be used to refer to any model of Mosin Nagant. These pictures have been reduced to allow faster loading of the page, but when sharing with other collectors they should be left as large as practical for maximum clarity of details.
Refer to "picture #1 (or #s 1, 5, 9, and 11; or #s 12 thru 18, etc.) at http://7.62x54r.net/MosinID/MosinPhotoII.htm"
Also see the Picture #1
Full length, right
side
Picture #2
Full length, left
side
Picture #3
Barrel and receiver
marks, top
Picture #4
Barrel marks, right
side
Picture #5
Barrel marks, left
side
Picture #6
Tang marks
Picture #8
Bolt, upright in
receiver showing number
Picture #9
Buttplate, from angle
showing number
Picture #10
Floorplate, showing
number
Picture #11
Buttstock, right
side
Picture #13
Buttstock, left side
Picture #14
Wrist, top with
cocking knob
Picture #15
Bolt, right side
closed in receiver showing number
Picture #18
Bolt, left side open
in receiver
Picture #19
Rear sight and
barrel band, top
Picture #20
Rear sight and
barrel band, right side
Picture #21
Rear sight and
barrel band, left side
Picture #22
Magazine tang and
rear barrel band, bottom
Picture #23
Rear barrel band,
bottom
Picture #24
Fore end, right side
Picture #25
Fore end, left side
Picture #26
Front barrel band
and nose cap, right side
Picture #28
Front barrel band
and nose cap, left side
Picture #29
Front barrel band
and nose cap, bottom
Picture #30
Front barrel band,
nose cap and front sight, top
Picture #31
Front barrel band,
nose cap and front sight, right side
Picture #32
Front barrel band,
nose cap and front sight, left side
Picture #33
Front sight, from
angle
Picture #34
Trigger guard and
magazine, right side
Picture #35
Trigger guard and
magazine, left side
Picture #36
Cross bolt and
finger groove, right side
Picture #38
Cross bolt and
finger groove, left side
Picture #39
Trigger and sear
with action removed from stock
Picture #40
Rear sight base with
action removed from stock
Picture #41
Bolt removed from
rifle, top
Picture #42
Bolt removed from
rifle, right side
Picture #43
Bolt removed from
rifle, left side
Picture #44
Handguard removed
from rifle, full length
Picture #45
Handguard removed
from rifle rear end cap
Picture #46
Handguard removed
from rifle front end cap
